toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comA m v e c o T o r o i d a l S o l u t i o n s
PRIMARY VOLTAGE — 115V or 230V at 50/60 Hz (CONT.)
Part
Number
Power
(VA)
Secondary
Voltage
(V)
Secondary
Current
(mA)
No
Load
Voltage
(V)
No
Load
Current
(mA)
Reg
%
∆
t
(ºC)
Eff
%
Length
(Inches)
(mm.)
Width
(Inches)
(mm.)
Height
(Inches)
(mm.)
Weight
Lbs.
(kg)
Pin Layout
X
In. (mm.)
Y
In. (mm.)
Pin Size
In.
(mm.)
70020K
5
2 x 7
357
2 x 9.7
2
40 29 68 1.96
(49.7)
1.96
(49.7)
0.77
(19.5)
0.32
(144)
45.72
45.72 0.04 x 0.02
(1.0 x 0.5 )
70021K
2 x 9
278
2 x 12.4
70022K
2 x 12
208
2 x 17.0
70023K
2 x 15
167
2 x 21.3
70024K
2 x 18
139
2 x 25.5
70025K
2 x 22
114
2 x 30.5
70030K
7
2 x 7
500
2 x 9.5
3
34 25 74 1.96
(49.7)
1.96
(49.7)
0.91
(23.1)
0.38
(174)
45.72
45.72 0.04 x 0.02
(1.0 x 0.5 )
70031K
2 x 9
389
2 x 12.2
70032K
2 x 12
292
2 x 16.2
70033K
2 x 15
233
2 x 20.3
70034K
2 x 18
194
2 x 24.3
70035K
2 x 22
159
2 x 29.7
70040K
10
2 x 7
714
2 x 8.3
3
20 24 82 2.17
(55)
2.17
(55)
1.02 (26)
0.56
(252)
50.8
50.8 0.04 x 0.02
(1.0 x 0.5 )
70041K
2 x 9
556
2 x 10.8
70042K
2 x 12
417
2 x 14.4
70043K
2 x 15
333
2 x 18.0
70044K
2 x 18
278
2 x 21.7
70045K
2 x 22
227
2 x 26.3
70050K
15
2 x 7
1071
2 x 8.9
4
23 27 80 2.36
(60)
2.36 (60)
1.04
(26.3)
0.67
(304)
55.88
55.88 0.04 x 0.02
(1.0 x 0.5 )
70051K
2 x 9
833
2 x 11.1
70052K
2 x 12
625
2 x 14.8
70053K
2 x 15
500
2 x 18.5
70054K
2 x 18
417
2 x 22.2
70055K
2 x 22
341
2 x 27.2
70060K
25
2 x 7
1785
2 x 8.3
5
19 28 83 2.36
(60)
2.36
(60)
1.48
(37.5)
0.96
(435)
55.88
55.88 0.04 x 0.02
(1.0 x 0.5 )
70061K
2 x 9
1377
2 x 10.7
70062K
2 x 12
1041
2 x 14.3
70063K
2 x 15
832
2 x 17.8
70064K
2 x 18
694
2 x 21.4
70065K
2 x 22
568
2 x 26.2
70070K
35
2 x 7
2500
2 x 8.0
7
17.7 31 81 2.83
(72)
2.83
(72)
1.48
(37.5)
1.16
(525)
66.04
66.04 0.04 x 0.04
(1.0 x 1.0 )
70071K
2 x 9
1944
2 x 10.6
70072K
2 x 12
1458
2 x 14.0
70073K
2 x 15
1167
2 x 17.6
70074K
2 x 18
972
2 x 20.9
70075K
2 x 22
795
2 x 25.7
