toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comA m v e c o T o r o i d a l S o l u t i o n s
ENCLOSED MEDICAL ISOLATION TRANSFORMERS
Acme Electric now offers a line of fully enclosed medical isolation transformers, featuring Amveco Toroidal Power technology. For medical
grade applications, these units provide additional safety and protection. When using electronic devices in a medical, these medical grade
transformers will bring the equipment into compliance with the UL 60601 medical safety standard. The transformers operate at 120V 60Hz
input with 120V output. They have built in RFI filtering and in-rush current limiting. The transformer design utilizes toroidal transformer which
offers light weight, high efficiency, quiet operation, cool overall temperature, and low stray magnetic field.
Features
Q
Fully enclosed medical isolation transformers housed in white aluminum enclosure
Q
Designed for North American 120V 60Hz input operation
Q
UL listed to UL 60601-1 and c-UL listed to CSA C22.2 No.601.1.
Q
High efficiency toroidal transformer design yielding overall compact size and low weight.
Q
Low leakage design. Less than 100 µA leakage current.
Q
Built in filtering with RFI interference and inrush protection.
Q
Surge suppression
Q
10 ft hospital grade power cord
Q
Duplex ‘green-dot’ hospital grade outlets
Q
On/Off circuit breaker
Q
Floor standing or wall mount
ENCLOSED MEDICAL ISOLATION TRANSFORMERS 120 VOLT PRIMARY — 120 SECONDARY VOLT — 60 Hz
VA Catalog Number
Width
(Inches)(Cm.)
Height
(Inches)(Cm.)
Length
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Load Regulation NEMA PLUG
Hospital Grade
Duplex Outlets
300
AS30327
5.63 (14.3)
4.13 (10.5)
10.00 (25.4)
10 (4.5)
4.5%
5-15P
(2) 5-15R
600
AS30328
7.13 (18.1)
4.13 (10.5)
12.50 (31.7)
17 (7.7)
2.9%
5-15P
(3) 5-15R
900
AS30329
7.13 (18.1)
4.13 (10.5)
12.50 (31.7)
26 (11.8)
1.5%
5-15P
(4) 5-15R
1200
AS30330
9.13 (23.2)
4.13 (10.5)
14.00 (35.6)
32 (14.5)
1.4%
5-15P
(4) 5-15R
1800
AS30331
9.13 (23.2)
4.13 (10.5)
14.00 (35.6)
37 (16.8)
1.7%
5-20P
(4) 5-20R
HEIGHT
LENGTH
WIDTH
