toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comA m v e c o T o r o i d a l S o l u t i o n s
Part Number
Current I DC
(Amps)
Current RMS
(Amps)
Inductance
(mH)
Power
(WS)
Core Losses
(W)
Copper Losses
(W)
OD x HT
Inches (mm.)
Weight
Lbs. (kg)
L0540
5
3.5
40
0.5
1.5
12.8
3.8 x 1.9 (97 x 48)
2.5 (1.1)
L0560
5
3.5
60
0.75
3
13.8
4.6 x 2.0 (117 x 51)
4 (1.8)
L1020
10
7
20
1
4
16.7
5.5 x 2.0 (140 x 51)
6 (2.7)
L1040
10
7
40
2
5
23.4
5.5 x 2.4 (140 x 61)
8 (3.6)
L1060
10
7
60
3
7
28.6
5.9 x 2.8 (150 x 71)
11.5 (5.2)
L1510
15
10.6
10
1.13
4
18.7
5.5 x 2.0 (140 x 51)
6 (2.7)
L1515
15
10.6
15
1.69
5
22.7
5.5 x 2.4 (140 x 61)
7.5 (3.4)
L1520
15
10.6
20
2.25
5
26.3
5.5 x 2.4 (140 x 61)
8 (3.6)
L1540
15
10.6
40
4.5
8
37.8
6.5 x 2.8 (165 x 71)
15 (6.8)
L2010
20
14.1
10
2
5
23.2
5.5 x 2.4 (140 x 61)
8 (3.6)
L2015
20
14.1
15
3
7
28.4
5.9 x 2.8 (150 x 71)
11.5 (5.2)
L2020
20
14.1
20
4
8
32.8
6.5 x 2.8 (165 x 71)
14 (6.4)
L2040
20
14.1
40
8
12
42.8
8.0 x3.5 (203 x 89)
27 (12.3)
L3005
30
21.2
5
2.25
5
26.1
5.5 x 2.4 (140 x 61)
8.5 (3.9)
L3010
30
21.2
10
4.5
8
37.8
6.5 x 2.8 (165 x 71)
15 (6.8)
L3015
30
21.2
15
6.75
11
45.9
8.0 x 3.0 (203 x 76)
22 (10)
L3020
30
21.2
20
9
13
43.2
8.0 x 3.5 (203 x 89)
28 (12.7)
L4005
40
28.3
5
4
8
32
6.5 x 2.8 (165 x 71)
14 (6.4)
L4010
40
28.3
10
8
13
43.2
8.0 x 3.5 (203 x 89)
27 (12.3)
L4015
40
28.3
15
12
20
56
10.0 x3.4 (254 x 86)
39 (17.7)
L5005
50
35.3
5
6.25
11
35
8.0 x 3.0 (203 x 76)
23 (10.4)
L5010
50
35.3
10
12.5
20
57.5
10.0 x 3.4 (254 x 86)
39 (17.7)
L6005
60
42.4
5
9
12
43.2
8.0 x 3.5 (203 x 89)
29 (13.2)
Notes:
Electrical measurements @ 20°C ambient temperature. All data subject to change without prior notice.
TOROIDAL POWER INDUCTORS
Many of the same features offered by our toroidal transformers are also true for our tor DC filtering and AC circuits. A toroidal DC filter
choke for line frequency operation used in conjunction with a toroidal power transformer allows our engineering to design a small size
transformer. Using toroidal DC filter chokes also reduces the size of the required filter capacitors.
