180 toll free 800.334.5214 ACME ELECTRIC |
A m v e c o T o r o i d a l S o l u t i o n s
PRIMARY VOLTAGE — 115V or 230V at 50/60 Hz (CONT.)
Part
Number
Power
(VA)
Secondary
Voltage
(V)
Secondary
Current
(mA)
No Load
Voltage
(V)
No Load
Current
(mA)
Reg % ∆ t
(ºC)
Eff %
Outside
Dimensions
(Inches)(mm.)
Inside
Dimensions
(Inches)(mm.)
Height
(Inches)(mm.)
Weight
Lbs. (kg)
62030P2S02
7
2 x 7 500 2 x 9.5
3 34 25 74 1.85 (47) 0.24 (6) 0.85 (21.5) 0.32 (145)
62031P2S02 2 x 9 389 2 x 12.2
62032P2S02 2 x 12 292 2 x 16.2
62033P2S02 2 x 15 233 2 x 20.3
62034P2S02 2 x 18 194 2 x 24.3
62035P2S02 2 x 22 159 2 x 29.7
62040P2S02
10
2 x 7 714 2 x 8.3
3 20 24 82 2.11 (53.5) 0.27 (6.8) 0.93 (23.5) 0.48 (216)
62041P2S02 2 x 9 556 2 x 10.8
62042P2S02 2 x 12 417 2 x 14.4
62043P2S02 2 x 15 333 2 x 18.0
62044P2S02 2 x 18 278 2 x 21.7
62045P2S02 2 x 22 227 2 x 26.3
62050P2S02
15
2 x 7 1071 2 x 8.9
4 23 27 81 2.26 (57.5) 0.28 (7) 0.94 (24) 0.58 (262)
62051P2S02 2 x 9 833 2 x 11.1
62052P2S02 2 x 12 625 2 x 14.8
62053P2S02 2 x 15 500 2 x 18.5
62054P2S02 2 x 18 417 2 x 22.2
62055P2S02 2 x 22 341 2 x 27.2
62060P2S02
25
2 x 7 1785 2 x 8.3
5 19 28 84 2.28 (58) 0.54 (13.8) 1.36 (34.5) 0.86 (388)
62061P2S02 2 x 9 1377 2 x 10.7
62062P2S02 2 x 12 1041 2 x 14.2
62063P2S02 2 x 15 832 2 x 17.8
62064P2S02 2 x 18 694 2 x 21.4
62065P2S02 2 x 22 568 2 x 26.2
62070P2S02
35
2 x 7 2500 2 x 8.4
7 17.7 31 85 2.83 (72) 0.67 (17) 1.32 (33.5) 1 (453)
62071P2S02 2 x 9 1944 2 x 10.6
62072P2S02 2 x 12 1458 2 x 14.0
62073P2S02 2 x 15 1166 2 x 17.6
62074P2S02 2 x 18 972 2 x 20.9
62075P2S02 2 x 22 795 2 x 25.7
62080P2S02
50
2 x 7 3571 2 x 8.1
8 15.5 30 86 3.07 (78) 0.89 (22.5) 1.38 (35) 1.48 (670)
62081P2S02 2 x 9 2777 2 x 10.4
62082P2S02 2 x 12 2083 2 x 13.8
62083P2S02 2 x 15 1666 2 x 17.3
62084P2S02 2 x 18 1388 2 x 20.7
62085P2S02 2 x 22 1136 2 x 25.4
Electrical measurements @ 20°C ambient temperature. All data subject to change without prior notice.
For 230V/240V operation, connect primaries in series by connecting black and red lead wires together and apply 230V across yellow and violet leads wires.
For 115V/120V operation, connect primaries in parallel by connecting yellow and red lead wires together and black and violet leads wires.
To parallel the secondaries, connect green and brown wires and red and blue together. To put the secondaries in series, the red and brown wires are connected together. Take the output
across the green and blue wires.
