toll free 800.334.5214 ACME ELECTRIC |

hubbell-acmeelectric.com

A m v e c o T o r o i d a l S o l u t i o n s

LOW PROFILE PC MOUNT TRANSFORMERS

Our 70000-series PC Mount toroidal step-down transformers offer the same features as our non-encapsulated toroidal power transformers,

namely, very low EMR (magnetic stray fields), quiet operation, low temperature rise, low profile, low no-load current and very low no-load

losses.

The cores are produced from a continuous strip of high grade silicon steel, and the windings are placed concentrically around the core.

This is the ideal magnetic path, lacking air gaps or discontinuities thereby optimizing the use of magnetic flux for power transformation and

significantly reducing idling currents when the load is removed.

Additionally, the transformers are designed for PCB mounting and can be secured prior to the soldering process through the use of a

central screw receptacle that will accommodate either M4/M5 metric machine screws, or self-tapping types.

Benefits

Q

Low profile

Q

Low magnetic field radiation

Q

Acoustic noise virtually eliminated

Q

Small size

Q

High efficiency

Q

Low leakage losses

Q

High isolation (4000VAC primary to secondary)

Features

Q

Safety standard certifications (UL 506, UL 1950, UL File E122978, E138299)

Q

VDE 0805, IEC 950, EN 60950

Q

UL recognized for insulation Class A (105C). Meets all requirements of Class E(125°C)

Q

UL and VDE certifications to +40°C (1.6VA - 25VA)

Q

Hipot testing at 4000V between primary and secondary. (VDE0550)

Q

Maximum ambient temperature of +60°C for 1.6VA-25VA, +40°C for 35VA and 50VA models

PRIMARY VOLTAGE — 115V or 230V at 50/60 Hz

Part

Number

Power

(VA)

Secondary

Voltage

(V)

Secondary

Current

(mA)

No

Load

Voltage

(V)

No

Load

Current

(mA)

Reg

%

t

(ºC)

Eff

%

Length

(Inches)

(mm.)

Width

(Inches)

(mm.)

Height

(Inches)

(mm.)

Weight

Lbs.

(kg)

Pin Layout

X

In. (mm.)

Y

In. (mm.)

Pin Size

In.

(mm.)

70000K

1.6

2 x 7

114

2 x 8.9

1

29 10 77 1.56

(39.6)

1.56

(39.6)

0.73

(18.5)

0.18 (82)

1.4

(35.56)

1.4

(35.56)

0.04 x 0.02

(1.0 x 0.5 )

70001K

2 x 9

89

2 x 11.6

70002K

2 x 12

67

2 x 15.4

70003K

2 x 15

53

2 x 19.3

70004K

2 x 18

44

2 x 23.4

70005K

2 x 22

36

2 x 28.2

70010K

3.2

2 x 7

229

2 x 10.2

1.5

43 20 70 1.76

(44.7)

1.76

(44.7)

0.77

(19.5)

0.24

(110)

40.64

40.64 0.04 x 0.02

(1.0 x 0.5 )

70011K

2 x 9

178

2 x 13.0

70012K

2 x 12

133

2 x 17.3

70013K

2 x 15

107

2 x 21.4

70014K

2 x 18

89

2 x 25.7

70015K

2 x 22

73

2 x 31.3
