PRIMARY VOLTAGE — 2 X 117V 50/60 Hz (CONT.)
Part Number
Nominal Power
(VA)
Secondary Voltage
(Volts)
Secondary Current
(Amps)
Core Loss
(Watts)
Copper Loss
(Watts)
OD x H
Inches (mm)
Weight
Lbs. (kg)
Mounting
Hardware
AA50502006
50
2 x 6
4.2
8.6
0.45
3.2 x 1.4 (81 x 36)
1.6 (0.7)
#10
AA50502009
2 x 9
2.8
8.6
0.45
AA50502012
2 x 12
2.1
8.6
0.45
AA50502015
2 x 15
1.7
8.6
0.45
AA50502018
2 x 18
1.4
8.6
0.45
AA50502022
2 x 22
1.1
8.6
0.45
AA50502024
2 x 24
1
8.6
0.45
AA50952009
95
2 x 9
2.8
16.0
0.90
3.9 x 1.5 (99 x 38)
2.2 (1)
1/4"
AA50952012
2 x 12
2.1
16.0
0.90
AA50952015
2 x 15
3.2
16.0
0.90
AA50952018
2 x 18
2.6
16.0
0.90
AA50952022
2 x 22
2.2
16.0
0.90
AA50952024
2 x 24
2
16.0
0.90
AA50952028
2 x 28
1.7
16.0
0.90
AA50952030
2 x 30
1.6
16.0
0.90
AA51402012
140
2 x 12
5.8
19.0
1.20
3.9 x 1.9 (99 x 48)
3 (1.4)
1/4"
AA51402015
2 x 15
4.7
19.0
1.20
AA51402018
2 x 18
3.9
19.0
1.20
AA51402022
2 x 22
3.2
19.0
1.20
AA51402024
2 x 24
2.9
19.0
1.20
AA51402028
2 x 28
2.5
19.0
1.20
AA51402030
2 x 30
2.3
19.0
1.20
AA51402117
2 x 117
0.6
19.0
1.20
AA51852012
185
2 x 12
7.7
20.0
1.40
4.5 x 1.9 (114 x 48)
4 (1.8)
1/4"
AA51852015
2 x 15
6.16
20.0
1.40
AA51852018
2 x 18
5.1
20.0
1.40
AA51852022
2 x 22
4.2
20.0
1.40
AA51852024
2 x 24
3.9
20.0
1.40
AA51852028
2 x 28
3.3
20.0
1.40
AA51852030
2 x 30
3.1
20.0
1.40
AA51852117
2 x 117
0.8
20.0
1.40
AA52402015
240
2 x 15
8
22.0
1.70
4.5 x 2.1 (114 x 53)
4.8 (2.2)
1/4"
AA52402018
2 x 18
6.7
22.0
1.70
AA52402024
2 x 24
5
22.0
1.70
AA52402030
2 x 30
4
22.0
1.70
AA52402038
2 x 38
3.2
22.0
1.70
AA52402117
2 x 117
1
22.0
1.70
