A m v e c o T o r o i d a l S o l u t i o n s
LOW PROFILE MINIATURE TRANSFORMERS
The 62000-series Miniature toroidal step-down transformers offers the design engineer the same features as our larger toroidal power
transformers, namely, very low EMR ( magnetic stray fields), quiet operation, low temperature rise, low profile, low no-load current and very
low no-load losses.
The cores are produced from a continuous strip of high grade silicon steel, and the windings are placed concentrically around the core.
This is the ideal magnetic path, lacking air gaps or discontinuities thereby optimizing the use of magnetic flux for power transformation and
significantly reducing idling currents when the load is removed.
Benefits
Q Lower Stray field
Q Higher Efficiency
Q Reduced “Standby” Current
Q Reduced Weight
Features
Q Safety standard certifications (UL 506, UL File E122978)
Q UL recognized for insulation Class A (105°C). Meets all requirements of Class E(125°C)
Q UL certifications to +40°C (1.6VA - 25VA)
Q Hipot testing at 4000V between primary and secondary.
Q Maximum ambient temperature of +60°C
Q Epoxy potted center with through hole for M4 bolt
PRIMARY VOLTAGE — 115V or 230V at 50/60 Hz
Part
Number
Power
(VA)
Secondary
Voltage
(V)
Secondary
Current
(mA)
No Load
Voltage
(V)
No Load
Current
(mA)
Reg % ∆ t
(ºC)
Eff %
Outside
Dimensions
(Inches)(mm.)
Inside
Dimensions
(Inches)(mm.)
Height
(Inches)(mm.)
Weight
Lbs. (kg)
62000P2S02
1.6
2 x 7 114 2 x 8.94
1 29 10 77 1.48 (37.5) 0.28 (7) 0.67 (17) 0.16 (71)
62001P2S02 2 x 9 89 2 x 11.63
62002P2S02 2 x 12 67 2 x 15.43
62003P2S02 2 x 15 53 2 x 19.30
62004P2S02 2 x 18 44 2 x 23.41
62005P2S02 2 x 22 36 2 x 28.19
62010P2S02
3.2
2 x 7 229 2 x 10.2
1.5 41 20 70 1.65 (42) 0.28 (7) 0.69 (17.5) 0.2 (89)
62011P2S02 2 x 9 178 2 x 13.0
62012P2S02 2 x 12 133 2 x 17.3
62013P2S02 2 x 15 107 2 x 21.4
62014P2S02 2 x 18 89 2 x 25.7
62015P2S02 2 x 22 73 2 x 30.5
62020P2S02
5
2 x 7 357 2 x 9.7
2 45 29 70 1.85 (47) 0.24 (6) 0.71 (18) 0.25 (115)
62021P2S02 2 x 9 278 2 x 12.4
62022P2S02 2 x 12 208 2 x 17.0
62023P2S02 2 x 15 167 2 x 21.3
62024P2S02 2 x 18 139 2 x 25.5
62025P2S02 2 x 22 114 2 x 30.5
