Wireless Interface
Monitor and control your onboard systems from your iPad
®
.
Mastervolt has produced a wireless interface that allows your
iPad to interface with an onboard digital switching system for
full monitoring and control of the electrical equipment via a
clear and intuitive display. The interface acts as a hub for the
seamless connection between the two popular Digital Switching
protocols of MasterBus and CZone.
Features:
• User-friendly homepage to monitor and control
onboard circuits.
• Integrated control and monitoring of power products
including battery chargers and inverters.
• Monitor AC/DC power and batteries.
• Monitor tank levels.
• Receive visible alarms.
• Connect a maximum of three devices simultaneously.
• Ability to personalize homepage to display favorite
circuits, modes & monitoring.
• Add your own layout.
• Connects to CZone or MasterBus networks for control
and monitoring of systems
WI Configuration Tool
• User friendly configuration tool for PC.
• Allows full customization of CZone app home page.
• Import multiple images for boat layout.
• Easy drag and drop of circuits and alarms onto boat image.
• Configure network settings on wireless server.
• Create user profiles for logging into the CZone app.
Hardware:
• The WiFi Interface acts as the hub between
MasterBus/CZone networks and local WiFi devices.
• NOTE: WI MasterBus connector required for
MasterBus connection.
• Ethernet connection to connect to other LANs.
• USB connection for configuration updates.
• Tested to FCC, CE, EMC.
• Power cable and aerial included.
80-911-0090-00
Wireless Interface
80-911-0095-00
WI MasterBus Connector
Manage:
CZone
™
Digital Control & Monitoring
TM
iPad
®
is a trademark of Apple Inc.
